The additional wire is tapped into the backup lights to disengage the hydraulic trailer coupler actuator when the vehicle is reversing thus turning off the trailers brakes. The 5th pin a blue wire gives power to operate the trailer brakes.

Trailer Breakaway Kit And How To Use It Mechanical Elements

Once you have these components you can begin to wire up the breakaway switch.

. Web A wiring diagram for a trailer breakaway switch is an essential part of installing the switch and ensuring the safety of the trailer and its contents. The wiring diagram shows the components that are needed for the installation the route taken by the wiring and the order of the wiring. Web The first step in creating a wiring diagram for your trailer with electric brakes and a breakaway system is to determine the type of brake controller you need.

Check and install battery and charger into the battery case. Wire per schematic diagram. The break away box will have 3 wires.

If the trailer has a more complicated wiring system such as one with multiple batteries a specialized diagram may be required. Web 3 Options for Installing Trailer Wiring on Your Vehicle. Web post Or Other suitable location orl trailer.

5-Way Flat Trailer Connector. The wiring to the battery and the wiring to the breakaway switch. 4 Battery box dimensions.

I explain the wiring and test it. Depending on your trailers weight youll need either a proportional or a. There are 3 wires coming off of the breakaway battery as you indicated.

This is critical for proper engagement of switch. Plug in shore power Attach a 12V battery to the trailer Connect the trailer to a tow vehicle 2. Splice one blue wire of the Break-Away Switch to the electric brake wire coming from the trailer side connector A - see diagram on next page.

Kit includes breakaway switch battery box and wiring. A wiring diagram for a trailer breakaway kit will often consist of two parts. Regardless of your method use a wiring diagram that is specific to your setup.

And lastly we will cover a bit more about the costs involved in this type of work. On this page typically below the product links there is a helpful link section that will have the install instructions fo the Hopkins Breakaway kit part 20400 that you referenced. Taillight converter that splices into your existing vehicle wiring and provides a standard trailer connector.

These components include the breakaway switch itself the battery the trailer wiring harness the brake controller and the trailer brakes. Blue wires are interchangeable on the Break-Away Switch 3. Propery insulate all connections.

The wiring diagram below shows the. Web WIRING DIAGRAM Step 1 - Mounting Position the breakaway switch on the tongue of the trailer so that it allows the cable to reach the tow vehicles trailer hitch safety chain eyelets. The breakaway switch is there in case the fifth-wheel trailer and.

The 5th wire can also be used to disable hydraulic brakes when in reverse Traditional Trailer with Brakes. Web I have attached a sample diagram for you below. Single-axle or tandem-axle trailers with electric braking systems.

Web Then we will discuss the diagram and how you can connect the trailer break away wiring to your trailer. Web Breakaway Switch Wiring TESTING THE BREAKAWAY SWITCH REPAIR 1. Bolt breakaway switch to frame of trailer Or battery case bracket.

Web Here is a wiring diagram for your Trailer Breakaway Kit. 5-18 long x 5-116 wide x 3-38 tall. A trailer breakaway switch wiring diagram includes several components.

Apply power to the trailer in one of 3 ways. Connect other blue wire of Break-Away Switch to the blue wire labeled Brake from the Break-Away box B. Web Use the wire already running from your trailer lights to the tow vehicle or run new wires directly from your brake controller to your trailer brakes.

The junction box on the front of the trailer should be open with wiring pulled out of the box. Web Typically the 5-Way Flat is used for trailers with surge brakes or hydraulic brakes. Web These diagrams show the entire electrical system of the trailer and provide basic instructions for connecting each component.

So if you want to learn more follow along. The black wire will tie into the 12 volt hot lead from the trailer connector. Vehicle-specific plug-and-play harness that requires no splicing and provides a standard trailer connector.

Web Convenient wiring diagram is printed on the box. To start off youll need to obtain the appropriate trailer breakaway switch for your trailer as well as a 7-way trailer plug. Web Fortunately wiring a trailer breakaway switch is a straightforward process that requires minimal tools and knowledge.

This will provide a trickle charge to the breakaway battery while you are towing. Web The trailer breakaway system wiring diagram will provide detailed instructions on how to connect the components of the system. The system splices into the existing trailer wiring.

Web If a trailer has brakes then it needs a connector with at least 5 wires. This little bit of schematic attaches into the full trailer wiring diagram from our other article. I also attached an install video that shows the kit installed as well as a diagram for trailer breakaway wiring as well.

Important Facts to Remember 12 Volt Sealed Lead-Acid Battery. One of our most top rated systems is the Hopkins Engager Push-To-Test Trailer Breakaway Kit part 20099. This type of diagram is best suited for trailers that have a standard wiring setup.

This includes the breakaway switch wiring harness and power source. Web Check out the wiring diagram I attached I think that will make more sense for you. Web Wiring Diagram for Trailer Breakaway Kit.

Feed wires out the back then close the top. Web In this video I replace my old worn looking trailer breakaway safety switch with a new one. Web We have a online diagram that will help you understand how the break away system is wired into your trailer.

This is typical but check your system to be sure the wires colors are the same. It is actually a simple installation. Its important to follow the diagram carefully and ensure that all the connections are correct.

With that being said I recommend replacing the system so you are able to ensure everything is in working order and is wired correctly. Web The Components of a Trailer Breakaway Switch Wiring Diagram.
